Building Skills: How to Build an Arched Rough Opening
In the previous Building Skills video, Scott Grice demonstrated one way to measure and layout a plywood arch. This week he shows how to create a curved doorway with two arched pieces of plywood.
Here’s the basic formula:
1. Measure, layout, and cut two plywood arches that represent the top of your arched door opening
2. Rip several pieces of wood blocking to the width of your framing lumber minus the thickness of the two pieces of plywood (in this case, a 2×4 minus two 3/8-in. pieces of plywood equals 2-3/4 inch wide blocking)
3. Nail blocking to the top and sides of the opening using a scrap of your plywood as a gauge to leave enough room to nail your arches flush with the framing (be sure the blocking on each side is up a few inches from the bottom of the arch)
4. Nail the arches to the blocking
5. Slip small pieces of blocking in between the arched plywood several inches apart; screw these blocks to the plywood. This will give you a nailing surface for the arched piece of drywall that will fit within the opening (be sure the blocking is flush with, but doesn’t protrude into the arched opening)
Now you’re ready for drywall.
