Guest post by Kristin Dispenza

Unlike traditional building design, which relies on two-dimensional drawings, building information modeling (BIM) provides design information in five dimensions: width, height, depth, time, and cost. More than just a construction plan, BIM also covers geographic information, light analysis, and details about a building’s components.

The resulting building information models include every layer of a building–not just a superficial line representation but a complete virtual construction with fine detail and depth. They include frame, mechanical, and electrical installations, and finish layers, such as drywall and paint. It’s all there, with associated costs and labor timetables–a complete model of the structure that can be manipulated in every dimension, including the schedule and budget, before anything at all is actually built.

Feel intimidated?
Let’s step back a few decades, when businesses began the full-scale adoption of personal computers and when software purchases would arrive in oversize cartons accompanied by entire sets of user manuals–sometimes as many as ten separate volumes! We all know that those days are gone, yet maybe when you imagine learning new software, somewhere in the back of your mind a vision of those ten manuals is lurking.

Add to that the fact that one thing hasn’t changed over those same decades: We are still seeing software releases that represent a completely new way of doing business, pushing us out of our comfort zone and challenging our day-to-day workflow. For the design and construction industries, this means BIM.

When it’s ‘just you’
Surveys conducted by Building Design & Construction over the past couple of years indicate that among large design firms, BIM adoption has topped 80%. The numbers also are growing among the nation’s top 50 home-building firms, and the promised benefits to the bottom line are being realized, with the principle benefits coming during construction, as critical details on how different systems interact are resolved before ground is broken, thereby eliminating job-site head scratching. BIM not only will help tailor ductwork layouts and waste lines that don’t require improvised chases and drops, but it will also prevent job-site design problems–such a roofline that makes it impossible to properly flash a window, or a bulkhead that forces a trim carpenter to cut down all the lintel casings along a corridor–which can be almost invisible in two dimensions.

With BIM, plans can be so accurate that your lumberyard could drill precise plumbing holes in your joists and wall studs, saving hours of on-site labor.

Unfortunately, among smaller design and construction firms, the number of early adopters has not been robust. Yet small firms know that they are competing in the same landscape as the larger ones, and that the practices that are becoming so established among the profession’s trailblazers will end up changing the work environment for everyone. Still, for most small firms, BIM continues to loom in the distance.

Joy Stark, industry marketing manager for the popular architecture design software company Autodesk, confirms that while some small firms have been convinced of the benefits of BIM and have adopted a new workflow, many others still haven’t made the move to BIM. In response, Autodesk started a conversation with a few of those reluctant firms several years ago to find out precisely what the barriers were. The two main culprits were time and expense. In a small firm, explains Stark, where there may only be two or three employees, committing the time to learn new software often takes too much time away from talking with clients or working on current projects. “Expenses often come right out of the owner’s pockets,” she says. “Sometimes it is a question of ‘Do I go on vacation, or do I invest in a software upgrade?’ Yet the pressure is on to provide the same services [as other firms].”

In the fall of 2011, Autodesk made its first response to these needs and launched Project Spark, a technology preview that was available through Autodesk Labs. According to Stark, goals for the project included lowering the barrier to entry for small firms and providing a BIM product that would be available at a lower price point, goals that were achievable by giving this user group a more focused set of features–essentially BIM lite.

It may not be as different as you think
The good news is that you may be further along in the learning process than you think you are, even if you have never navigated through a BIM screen before.

John Klockeman, Fellow, AIA, had been in practice for over 30 years and had plenty of experience working with Autodesk’s Revit Architecture as a manager in a large design/build firm in Minnesota. But in 2010, he started his own firm, Rebuild Studio LLC–a sole proprietorship he runs out of his home–and he had to approach BIM from a different angle.

“I wanted to capture the same labor savings [that I had at the larger firm],” says Klockeman. Being new to the hands-on realm of BIM, though, he says that he “faced the same learning curve and resource commitment” as other small practitioners. Klockeman began by implementing the preview technology available from Project Spark for a small apartment remodel in Minneapolis. “All of the basic steps–putting in walls and so on–were very intuitive,” he says, “so I was encouraged to delve further into it.” Next, Klockeman used the technology during the remodel of a charter school that had existing space in a retail mall. “In Spark, it was easy to produce as-built drawings and then move on to making a conceptual model.” From that point, Klockeman was able to generate a professional set of construction drawings, which he describes as “complete with doors, windows, student cubicles.” He calls it “a good level of detail to give to the contractor.”

According to Scott Latch, Revit Architecture product manager, the newly released Revit LT “improves upon Project Spark in that it has better interoperability, so moving files [both DWG and RVT file formats] back and forth can occur; this makes collaboration with other trades pretty seamless.”

The key point for those facing the prospect of carving out time to learn BIM is that the process does not require learning a whole new design language. In fact, according to Klockeman, anyone who has a background in hand drawing is well poised to get up and running with BIM quickly.

What’s missing is the drudgery. “You get a quick, accurate plan from field measurements,” says Klockeman. “On-screen dimensions come up, so the drawings are accurate right away, and things such as self-healing corners save time … I’m convinced that BIM is the future. Coordination problems are eliminated because everything is generated from the same parametric [model], so changes to one window, for example, are changed everywhere. The amount of stress this eliminates is worth its weight in gold. The program thinks along with you, so you don’t have to work so hard.”

Help is easy to find
If you prefer a more structured way of learning, there are plenty of step-by-step resources available. An Autodesk WikiHelp offers a series of “Essential Skills” videos as well as a 13-part tutorial. The videos explain the fundamental features of Revit LT, and at about two minutes apiece, they are easy to fit into spare moments. The tutorials, which contain exercise files as well as “Getting Started” videos, provide a more complete understanding of Revit LT’s processes. A wealth of blogs offer help ranging from videos and tutorials to informal discussions, where you can have more specific questions answered (see, for example, Revit, by blogger David Light; and Revit Forum, an independent, nonprofit discussion group). Finally, there is always the option of working with an expert. A growing number of BIM consultancies have sprung up in recent years. Consultants can work with you one-on-one, and help you make decisions that are tailored to your company.

One new technology facilitates another
Not only are piles of floppy disks and big product cartons things of the past, but now some hardware requirements are, too. Cloud computing has taken off in the past year, and according to Stark, that is making it easier for small firms to adopt new technologies because they no longer need the same level of in-house infrastructure and communications channels that they once did. Instead, the cloud operates as a service. Revit LT rendering is done exclusively in the cloud, which, says Latch, “takes the load off of individual PCs.” With an active subscription to Revit LT, users have access to Autodesk 360 cloud rendering. In Revit LT’s rendering capabilities, too, says Latch, the program offers simplicity, with only a few settings to master.

You may not be ready for BIM today, but you won’t be able to put it off forever. Increasingly, firms like Autodesk are developing products for small design/build firms, so you can now make the switch for less money, for less time invested in learning new software, and without necessarily having to upgrade your hardware. That, in turn, should enable you to see a return on your investment in a shorter time frame.

__________________________________________________________________________________________

Kristin Dispenza is the managing editor for Buildipedia.com. You can reach her at [email protected].

__________________________________________________________________________________________

Autodesk Revit LT 2013 is available as a standalone version and as part of the new AutoCAD Revit LT Suite 2013, which includes both Autodesk Revit LT 2013 and AutoCAD LT 2013. Details and purchasing options are available at www.autodesk.com/revitlt
